As long as users master certain professional maintenance knowledge, it will be of great help in use. But mechanical oil leakage is a very common problem, but today you will learn some tips, automatic feeding mixer "stop oil leakage" 8 points is enough!
使用时间长,油封磨损正常。方法:更换新的油封。
Long service life, normal wear of oil seal. Solution: replace the oil seal with a new one.
油长时间未更换,滤芯质量不合格,油太脏,从而加速油封磨损。方案:尽快更换液压油和滤芯。
The oil has not been replaced for a long time, the filter element quality is unqualified, and the oil is too dirty, thus accelerating the wear of the oil seal. Solution: change the hydraulic oil and filter element as soon as possible.
传动轴平衡失灵,摆动动量大,导致主轴摆动油封偏心磨损。处理方案:及时正确更换转轴。
The balance of the transmission shaft is out of order and the swing momentum is large, which leads to eccentric wear of the swing oil seal of the main shaft. Treatment plan: replace the shaft timely and correctly.
液压油变质、乳化,导致润滑性能下降,加速油封磨损。方案:尽快更换液压油和滤芯。
The deterioration and emulsification of hydraulic oil results in the decrease of lubrication performance and the acceleration of oil seal wear. Solution: change the hydraulic oil and filter element as soon as possible.
泵支架松动,泵打开,泵固定螺栓松动,导致液压泵整体晃动,油封磨损。方案:经常检查和排除自动上料混合机可能出现的故障,防止和避免故障的发生。
The pump bracket is loose, the pump is opened, and the pump fixing bolt is loose, which causes the overall shaking of the hydraulic pump and the wear of the oil seal. Solution: frequently check and eliminate the possible faults of the automatic feeding mixer to prevent and avoid the occurrence of faults.
自动上料搅拌器系统回油不通畅,回油管道和散热器堵塞,导致电机壳体压力增大,油封漏油。方法:堵塞,保持油的流动。
The oil return of the automatic feeding agitator system is not smooth, the oil return pipeline and radiator are blocked, which causes the pressure of the motor shell to increase and the oil seal to leak. Solution: remove the blockage and keep the oil flowing.
散热器不加热,导致油温过高,粘度过高,润滑、油封过热,密封失效等问题。方案:散热器故障,对系统进行冷却处理,避免泵电机磨损。在严重的情况下,需要停止和关闭火,然后用水冲洗泵电机和散热器外壳,以达到冷却效果。
If the radiator is not heated, the oil temperature will be too high, the viscosity will be too high, the lubrication and oil seal will overheat, and the seal will fail. Solution: eliminate the radiator fault, cool the system and avoid the pump motor wear. In severe cases, it is necessary to stop and shut down the fire, and then flush the pump motor and radiator housing with water to achieve cooling effect.
在冬季,如果汽车预热不够,油温会过低,油封和油液不会达到理想的工作温度。处理方案:启动小车时,将油箱停车,怠速10min ~ 20min,待油温正常后将油箱转工作状态。
In winter, if the car is not preheated enough, the oil temperature will be too low, and the oil seal and fluid will not reach the ideal working temperature. Treatment scheme: when starting the trolley, stop the oil tank, idle for 10min ~ 20min, and turn the oil tank to the working state after the oil temperature is normal.
自动上料混合机液压泵轴端油封属于易损件。如果严格按照相关规范操作,许多漏油现象将得到有效预防。
The oil seal at the shaft end of the hydraulic pump of the automatic feeding mixer is a vulnerable part. If we operate in strict accordance with the relevant specifications, many oil leaks will be effectively prevented.
